product Introduction
①956 loader adopts Weichai Steyr diesel engine with strong power, low fuel consumption, low noise and reliable performance; it is equipped with double-stage air filter as standard, which is suitable for dusty workplaces.
②Adopt central articulated frame, small turning radius, flexible maneuverability, good lateral stability, easy to operate in narrow sites.
③Adopting full hydraulic steering, power shift and gear change, hydraulic operation of working device, the whole machine is light and flexible, smooth and reliable.
④Adopt air-over-oil caliper disc type four-wheel braking system to ensure the safety of traveling, smooth braking, safe and reliable.
⑤The double-pump combined flow and coaxial flow amplification system improve the working efficiency and economy. Pilot control makes the operation more flexible and comfortable. Folding large side door steel engine cover is beautiful and easy to maintain.
product Parameter (specification)
|
Performance |
||
|
Load lifting capacity |
5000KG |
|
|
Operating weight |
16500KG |
|
|
Rated bucket capacity |
3m³ |
|
|
Max.Traction force |
145KN |
|
|
Max.Breakout force |
175KN |
|
|
Max.Grade ability |
30° |
|
|
Max.Dump height |
3100mm |
|
|
Max.Dump reach |
1250mm |
|
|
Overall dimension(L×W×H) |
8085×2950×3450mm |
|
|
Min.Turning radius |
6840mm |
|
|
Engine |
||
|
Model |
Weichai |
|
|
Type |
Vertical in-line, water-cooled, four-stroke |
|
|
Cylinders - Inner diameter × stroke |
6-126×130 |
|
|
Rated power |
162KW |
|
|
Max.torque |
980N.m |
|
|
Min.fuel consumption |
≤213g/kw.h |
|
|
Transmission system |
||
|
Torque converter |
YJSW315 |
|
|
Gearbox model |
行星式Planetary |
|
|
Gears |
前进2档,后退1档2 forward,1 reverse |
|
|
Max.Speed |
36KM/H |
|
|
Driving axle |
||
|
Wheel base |
3250mm |
|
|
Wheel tread |
2250mm |
|
|
Ground clearance |
450mm |
|
|
Hydraulicsystem |
||
|
System working pressure |
18Mpa |
|
|
Boom lifting time |
5.95±0.2s |
|
|
Total time |
10.95±0.5s |
|
|
Fuel tank capacity |
249L |
|
|
Self-leveling bucket |
YES |
|
|
Brake system |
Service brake |
Air-over-oil caliper disc four-wheel brake |
|
Parking brake |
Manual brake |
|
|
Tyres |
Model |
23.5-25 |
|
Front Tyre Pressure |
0.4Mpa |
|
|
Rear Tyre Pressure |
0.35Mpa |
|
|
The above parameters are subject to change without prior notice. |
||
